Home Assistant provides a robust platform for automating your home, but to truly unlock its potential and build sophisticated, context-aware automations, you need to leverage its built-in templating engine, powered by Jinja2. While basic automations can handle simple triggers and actions, templating allows you to introduce dynamic data, complex logic, and personalized responses into almost every aspect of your configuration, from notifications and scripts to sensor definitions and UI elements.

What is Jinja2 Templating in Home Assistant?

At its core, templating allows you to generate text dynamically based on data available within Home Assistant. This data includes the states and attributes of your entities, configuration variables, and various functions and filters provided by Home Assistant.

You'll encounter Jinja2 templating in many places:

  • Automation conditions and actions (especially `template` conditions and service data).
  • Script service calls.
  • Notifications (creating dynamic messages).
  • Template sensors, binary sensors, and other template entities.
  • Customizing Lovelace dashboards.
  • MQTT payloads.

The basic syntax involves:

  • {{ state_or_attribute }}: To output the value of a variable or expression.
  • {% control_structure %}: For logic like loops, conditionals, and variable assignments.

Getting Started: The Developer Tools Template Editor

Your best friend when learning and using Home Assistant templating is the Developer Tools -> Template editor in the Home Assistant UI. This live editor allows you to write templates and immediately see the rendered output based on the current state of your entities. Use it extensively to test snippets before putting them into your configuration files or automation UI.

Core Concepts and Common Use Cases

Accessing Entity States and Attributes

The most common use is accessing the state or attributes of an entity. The `states` object holds the state of all entities.

The living room light is {{ states('light.living_room') }}.
The temperature is {{ states('sensor.living_room_temperature') }}°C.

To access attributes, you use `states.entity_id.attributes.attribute_name` or the more robust `state_attr()` function, which handles cases where the entity or attribute might not exist yet.

Brightness of light: {{ state_attr('light.living_room', 'brightness') }}.
Fan speed: {{ state_attr('fan.ceiling_fan', 'speed') }}.

Using the `state_attr` function is generally preferred:

{% set brightness = state_attr('light.living_room', 'brightness') %}
{% if brightness is not none %}
The light brightness is {{ brightness }}.
{% else %}
Brightness attribute not available.
{% endif %}

Filters: Transforming Data

Filters allow you to modify or transform the data you are outputting. They are added using the pipe symbol `|`.

Temperature rounded: {{ states('sensor.living_room_temperature') | float | round(1) }}°C.
State in uppercase: {{ states('binary_sensor.door_front') | upper }}.
Default value if state is unavailable/unknown: {{ states('sensor.non_existent') | default('N/A') }}.
Last changed time: {{ states.light.living_room.last_changed.timestamp() | timestamp_local }}.

Common filters include `float`, `int`, `round`, `upper`, `lower`, `capitalize`, `default`, `format`, `timestamp_local`, `as_datetime`, and many more.

Conditional Logic (`if/else`)

Jinja2 allows you to include logic directly within your templates using `{% if ... %}`, `{% elif ... %}`, and `{% else %}`.

The door is {% if is_state('binary_sensor.door_front', 'on') %}open{% else %}closed{% endif %}.

Notification: {% if states('sensor.battery_level') | float < 15 %}
Battery level is low ({{ states('sensor.battery_level') }}%). Please charge soon!
{% else %}
Battery level is sufficient ({{ states('sensor.battery_level') }}%).
{% endif %}

Note the use of `is_state` and `is_state_attr` functions, which are convenient Home Assistant additions.

Loops (`for`)

You can iterate over lists or dictionaries. This is powerful for generating messages or processing groups of entities.

{% for light in states.light %}
- {{ light.name }}: {{ light.state }}
{% endfor %}

List of open doors:
{% for door in states.binary_sensor | selectattr('attributes.device_class', '==', 'door') | selectattr('state', '==', 'on') %}
- {{ door.name }}
{% endfor %}

The second example shows combining loops with filters (`selectattr`) to only process entities matching certain criteria.

Template Sensors

Template entities (like `template` sensors or binary sensors) use templating to define their state and attributes dynamically based on other entities. This is crucial for creating virtual sensors or transforming data.

# Example in configuration.yaml or split files
template:
  - sensor:
      - name: "Combined Temperature and Humidity"
        state:
          "{{ states('sensor.living_room_temperature') }}°C / {{ states('sensor.living_room_humidity') }}%"
      - name: "Outside Temperature Status"
        state:
          {% set temp = states('sensor.outside_temperature') | float %}
          {% if temp < 5 %}
            Freezing
          {% elif temp < 15 %}
            Cold
          {% elif temp < 25 %}
            Mild
          {% else %}
            Warm
          {% endif %}
        unit_of_measurement: "status"

Dynamic Service Calls

You can use templates to define parameters for service calls in automations or scripts, allowing the action to change based on triggers or conditions.

# Example automation action
service: notify.mobile_app_my_phone
data:
  title: "Appliance Status Update"
  message: "The washing machine is now {% if is_state('binary_sensor.washing_machine_status', 'on') %}running{% else %}finished{% endif %}."
  data:
    # Send different importance based on state
    priority: "{% if is_state('binary_sensor.washing_machine_status', 'off') %}high{% else %}low{% endif %}"

Best Practices for Reliable Templating

  1. Use the Developer Tools: Test every template snippet thoroughly before deployment. This is the single most important practice.

  2. Handle Missing Data: Always assume that entity states or attributes might be unavailable or unknown, especially after Home Assistant restarts or entity unavailability. Use the `| default('...')` filter or check with `is not none` / `is defined`.

    The sensor value is {{ states('sensor.potentially_missing') | default('unavailable') }}.

    {% set attr_value = state_attr('light.mylight', 'non_existent_attribute') %}
    Attribute value: {% if attr_value is defined and attr_value is not none %}{{ attr_value }}{% else %}Attribute not found{% endif %}.

  3. Be Mindful of Data Types: States are often strings. If you need to perform mathematical comparisons, convert them using `| float` or `| int`.

    {% set temp = states('sensor.outside_temperature') | float %}
    {% if temp < 0 %}
      It's freezing!
    {% endif %}

  4. Keep Templates Readable: Complex templates can become difficult to manage. Use whitespace and indentation (though not strictly required by Jinja2, it helps readability). For very complex logic, consider using Python Scripts or AppDaemon.

  5. Understand Rendering Context: Templates in different contexts (e.g., template sensors vs. automation actions) might be evaluated at different times. Template sensors update when their *watched* entities change state (if configured correctly), while automation action templates are evaluated only when the action is triggered.

  6. Comment Complex Logic: For intricate templates, add comments using `{# This is a comment #}` to explain your logic.

Troubleshooting Template Issues

Template errors can manifest as warnings or errors in the Home Assistant logs. Look for messages related to `TemplateError`. Often, the error message will point to the specific issue, like trying to access an attribute of a `None` object or a syntax error.

The Developer Tools -> Logbook or the Home Assistant log file (`home-assistant.log`) are your primary resources here.

Conclusion

Mastering Jinja2 templating is a significant step in becoming a Home Assistant power user. It transforms your smart home from a collection of devices into a dynamic, responsive ecosystem. By understanding how to access data, use filters, implement conditional logic, and follow best practices for reliability, you can create truly custom and intelligent automations and interactions tailored exactly to your needs.

Start small, use the Developer Tools editor, and gradually incorporate templating into your notifications, sensors, and automations. The possibilities are vast!
