Integrating InfluxDB and Grafana with Home Assistant for Advanced Data Analysis

Home Assistant's built-in recorder is excellent for storing state history locally for short periods. However, for long-term analysis , advanced charting , and performance monitoring , integrating a time-series database like InfluxDB paired with a visualization tool like Grafana is a game-changer.

This powerful duo allows you to store years of data , identify trends , optimize energy usage , and debug issues with ease.

Why Use InfluxDB and Grafana?

Long-Term Data Storage:
Store historical data for months or years without burdening your Home Assistant instance.

Advanced Visualization:
Create rich, interactive dashboards in Grafana with graphs, gauges, and tables that go far beyond the default history graphs.

Performance:
InfluxDB is optimized for time-series data, offering better performance for querying large datasets compared to relational databases often used by the default recorder.

Analysis:
Correlate data from different sensors, calculate statistics, and gain deeper insights into your smart home's behavior.

Setup Steps

1. Install InfluxDB

The simplest way is often using Docker:

docker run -d --name influxdb -p 8086:8086 influxdb:1.8

Note: Using 1.x is common for older HA documentation; 2.x is also viable but has a different configuration.

Create a database and a user/password within InfluxDB.

2. Install Grafana

Again, Docker is recommended:

docker run -d --name grafana -p 3000:3000 grafana/grafan

Access Grafana on port 3000 and log in (default credentials: admin/admin).

3. Configure Home Assistant Recorder

Edit configuration.yaml. It's crucial to exclude entities you don't need in InfluxDB from the default recorder to save resources. You may optionally include only essential entities if you have many.

recorder:
  purge_keep_days: 7  # Keep local history short
  exclude:
    domains:
      - automation
      - script
      - group
      - input_boolean
    entity_globs:
      - "sensor.uptime*"
      - "*/state"
    entities:
      - sensor.last_boot

Restart Home Assistant after making changes.

4. Configure Home Assistant InfluxDB Integration

Add the InfluxDB integration via the UI (Settings → Devices & Services → Add Integration) or manually add to configuration.yaml.

influxdb:
  host: YOUR_INFLUXDB_HOST_IP
  port: 8086
  database: YOUR_DATABASE_NAME
  username: YOUR_USERNAME
  password: YOUR_PASSWORD
  ssl: false
  verify_ssl: false
  api_version: 1  # Or 2 if using InfluxDB 2.x

  # Optional: Specify included/excluded entities specifically for InfluxDB
  # include:
  #   domains:
  #     - sensor
  #     - binary_sensor
  # exclude:
  #   entities:
  #     - sensor.unnecessary_data

Restart Home Assistant after configuring in configuration.yaml. Data should start flowing into InfluxDB.

5. Configure Grafana Data Source

In Grafana, go to:

Connections → Data sources → Add data source → InfluxDB

Enter the connection details (URL, database, user, password) pointing to your InfluxDB instance. Save and test.

6. Create Dashboards

Start creating dashboards and panels in Grafana, selecting your InfluxDB data source and writing Flux or InfluxQL queries to visualize your Home Assistant data.

Device Integration Tips & Best Practices

Be Selective:
Don’t send all data to InfluxDB. Focus on sensors, energy meters, temperature/humidity, power consumption, and any other data you genuinely want to analyze over time. Exclude noisy or low-value data points.

Use Include/Exclude Filters:
Leverage the include and exclude options in the Home Assistant InfluxDB configuration to control exactly which entities' data is sent. This significantly reduces storage requirements and improves query performance.

Data Retention:
Configure retention policies in InfluxDB to automatically prune old data you no longer need, preventing your database from growing infinitely.

Security:
Ensure your InfluxDB and Grafana instances are not exposed to the public internet without proper security measures (firewall, authentication, potentially reverse proxy with SSL). Use strong, unique credentials for the database user.

Monitor Resources:
Keep an eye on disk space used by InfluxDB and the resource usage of Home Assistant, InfluxDB, and Grafana. Optimize configurations if needed.

Conclusion

Integrating InfluxDB and Grafana with Home Assistant transforms your historical data from simple logs into a powerful analytical tool. While requiring a bit more setup than the default, the ability to visualize trends, analyze energy consumption, and retain data long-term makes it an invaluable addition for serious smart home enthusiasts.

Start by sending a few key sensors and gradually expand as you become more familiar with the tools.
